TECHNICAL SPECIFICATIONS Dispersion HxV   60x40º Throat diameter   25 mm 1 in Horizontal beamwidth   60º (+10º -5º) (-6dB 2 - 16kHz) Vertical beamwidth   40º (+31º -2º) (-6dB 3 - 16kHz) Directivity factor (Q)   14.1 (media/average 800 - 16kHz) Directivity index (DI)   11dB (+2dB -6.4dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   202x202x145mm Baffle cutout dimensions (WxH)   177x177mm Net weight   1 kg 2.2 lb Total weight   1.3 kg 2.86 lb Material   Aluminium

TECHNICAL SPECIFICATIONS Dispersion HxV   60x50º Throat diameter   36 mm 1.4 in Horizontal beamwidth   60º (+27º -6º) (-6dB 1 - 16kHz) Vertical beamwidth   50º (+20º -1º) (-6dB 2.5 - 16kHz) Directivity factor (Q)   11.1 (media/average 0.63 - 16kHz) Directivity index (DI)   10.3dB (+1.9dB -2.4dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   235x235x121mm Baffle cutout dimensions (WxH)   204x202mm Net weight   1.2 kg 2.64 Ib. Total weight   1.53 kg 3.37 lb Material   Aluminium Construction   Cast Aluminium.  Connection of driver by 4 screws

TECHNICAL SPECIFICATIONS Dispersion HxV   80x50º Throat diameter   36 mm 1.4 in Horizontal beamwidth   80º (+16º -32º) (-6dB 1 - 20kHz) Vertical beamwidth   50º (+29º -14º) (-6dB 1.6 - 20kHz) Directivity factor (Q)   12.4 (media/average 0.63 - 16kHz) Directivity index (DI)   10.5dB (+3.5dB -3.2dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   235x235x120mm Baffle cutout dimensions (WxH)   204x202mm Net weight   1.2 kg 2.64 Ib. Total weight   1.53 kg 3.37 lb Material   Aluminium Construction   Cast Aluminium.  Connection of driver by 4 screws

TECHNICAL SPECIFICATIONS Dispersion HxV   60x40º Throat diameter   49 mm 2 in Horizontal beamwidth   60º (+18º -20º) (-6dB 0.63 - 16kHz) Vertical beamwidth   40º (+16º -12º) (-6dB 1.6 - 16kHz) Directivity factor (Q)   18.5 (media/average 0.63 - 16kHz) Directivity index (DI)   12.7dB (+3.1dB -4.1dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   420x270x227mm Baffle cutout dimensions (WxH)   365x235mm Net weight   2 kg 4.4 lb Total weight   2.8 kg 6.17 lb Material   Rigid polyurethane foam Construction   Rygid polyurethane foam. Aluminium adaptor.  Connection

TECHNICAL SPECIFICATIONS Dispersion HxV   80x60º Throat diameter   25 mm 1 in Horizontal beamwidth   80º (-6dB, 2 - 16kHz) Vertical beamwidth   60º (-6dB, 2 - 16kHz) Directivity factor (Q)   10.3 (media/average 1- 16kHz) Directivity index (DI)   7.7dB (+4dB -3.7dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   140x140x67.4 mm Baffle cutout dimensions (WxH)   113x130 mm Net weight   0.130kg 0.28 lb Total weight   0.225 kg 0.50 lb Material   Polycarbonate

TECHNICAL SPECIFICATIONS Dispersion HxV   90x40º Throat diameter   25 mm 1 in Horizontal beamwidth   90º (+2º -18º) (-6dB 2 - 16kHz) Vertical beamwidth   40º (+34º -3º) (-6dB 2 - 16kHz) Directivity factor (Q)   11.2 (media/average 800 - 16kHz) Directivity index (DI)   10.2dB (+2dB -6.4dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   202x202x145mm Baffle cutout dimensions (WxH)   177x177mm Net weight   1 kg 2.2 lb Total weight   1.3 kg 2.86 lb Material   Aluminium   SHARE

TECHNICAL SPECIFICATIONS Dispersion HxV   90x20º Throat diameter   12x208 mm 0.47x8.19 in Horizontal beamwidth   90º (+22º -46º) (-6dB 1.2 - 16kHz) Vertical beamwidth   20º (+27º -15º) (-6dB 2 - 16kHz) Directivity factor (Q)   60 (media/average 1.2 - 16kHz) Directivity index (DI)   15.5dB (+7dB -8.1dB)   CONSTRUCTIVE DETAILS Dimensions (WxHxD)   210x250x147mm Baffle cutout dimensions (WxH)   174x247mm Net weight   1.5 kg 3.3 lb Total weight   1.8 kg 3.96 lb Material   Aluminium
