Nou
difuzor Beyma 15LEX1000Fe
difuzor Beyma 12Lex1000Fe
<span class="woocommerce-Price-amount amount"><bdi>226,95 <span class="woocommerce-Price-currencySymbol">€</span></bdi></span> + TVA
difuzor Beyma 15LEX1600Fe
<span class="woocommerce-Price-amount amount"><bdi>284,95 <span class="woocommerce-Price-currencySymbol">€</span></bdi></span> + TVA
In Stock
222,95 € + TVA
putere: |
1000 W AES |
sensibilitate: |
97 dB/1W/1M |
domeniu de frecvenţă: |
40-1000 Hz |
impedanţă: |
8 Ohm |
frecvenţă rezonanţă: |
41 Hz |
preţ kit reparaţii: |
98,95 Euro+TVA |
Descărcări: 15LEX1000Fe
15LEX1000Fe
TECHNICAL SPECIFICATIONS
Nominal diameter |
380 mm 15 in |
Nominal impedance |
8 Ohm |
Minimum impedance |
7.4 ohm |
Power capacity |
1000 W AES |
Program power |
2000 W |
Sensitivity |
97 dB 1 W/1 m @ ZN |
Frequency range |
40-1000 Hz |
Recommended enclosure volume |
115 l |
Voice coil diameter |
88.9 mm 3.5 in |
BL factor |
23.2 N/A |
Moving mass |
0.142 kg |
Winding length |
27 mm |
Air gap height |
12 mm |
Xdamage pp |
51 mm |
THIELE SMALL PARAMETERS
Fs |
41 Hz |
Re |
5.4 ohm |
Qms |
5.1 |
Qes |
0.37 |
Qts |
0.34 |
Vas |
116 l |
Cms |
106 µm / N |
Rms |
7.2 kg/s |
Efficiency % |
2.1 |
Sd |
0.088 m² |
Xmax |
11 mm |
Vd |
968 cm³ |
Le @1 kHz |
1.7 mH |
CONSTRUCTIVE DETAILS
Depth |
182 mm 7.2 in |
Net weight |
11 kg 24.2 lb |
Total weight |
12 kg 26.4 lb |
Magnet |
Ferrite |
