difuzor Beyma 15LX60 V2
difuzor Beyma 15P80Nd
<span class="woocommerce-Price-amount amount"><bdi>367,95 <span class="woocommerce-Price-currencySymbol">€</span></bdi></span> + TVA
difuzor Beyma 15MC700
<span class="woocommerce-Price-amount amount"><bdi>197,95 <span class="woocommerce-Price-currencySymbol">€</span></bdi></span> + TVA
In Stock
215,95 € + TVA
putere: |
700 W AES |
sensibilitate: |
98 dB/1W/1M |
domeniu de frecvenţă: |
30-1500 Hz |
impedanţă: |
8 Ohm |
frecvenţă rezonanţă: |
42 Hz |
preţ kit reparaţii: |
87,95 Euro+TVA |
Descărcări: 15LX60V2
Category: 15 inch
TECHNICAL SPECIFICATIONS
Nominal diameter |
380 mm 15 in |
Nominal impedance |
8 Ohm |
Minimum impedance |
7.2 ohm |
Power capacity |
700 W AES |
Program power |
1400 W |
Sensitivity |
98 dB 1 W @ 1 m |
Frequency range |
30-1500 Hz |
Recommended enclosure volume |
60 / 150 l 2.12 / 5.3 ft³ |
Voice coil diameter |
100 mm 4 in |
BL factor |
21.1 N / A |
Moving mass |
0.147 kg |
Winding length |
20 mm |
Air gap height |
10 mm |
Xdamage pp |
58 mm |
THIELE SMALL PARAMETERS
Fs |
42 Hz |
Re |
5.1 ohm |
Qms |
21.23 |
Qes |
0.45 |
Qts |
0.44 |
Vas |
105.53 l |
Cms |
92.4 µm / N |
Rms |
1.9 kg / s |
Efficiency % |
1.67 |
Sd |
0.091 m² |
Xmax |
9 mm |
Vd |
812 cm³ |
Le @1 kHz |
2.1 mH |
CONSTRUCTIVE DETAILS
Net weight |
10.2 kg 22.49 lb |
Total weight |
13.30 kg 29.3 lb |
Magnet |
Ferrite |
